Lagertyp: Zwei Kugellager
Material: Impeller &Rahmen: Kunststoff (UL94V-0)
Bleidraht: UL1007 im Kombi,AWG26
nbsp; Red Wire Positiv (+)
nbsp; Negativ (Black Wire)一)
Gewicht: 165.g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA012025_12L | B/S//F | 12 | 7.0~13.2 | 0.36 | 2500 | 91.9 | 5.5 | 37 |
| WSA012025_24L | B/S/F | 24 | 14.0~26.4 | 0.25 | 2500 | 91.9 | 5.5 | 37 |
| WSA012025_12M | B/S/F | 12 | 7.0~13.2 | 0.53 | 2800 | 103 | 6.9 | 40 |
| WSA012025_24M | B/S/F | 24 | 14.0~26.4 | 0.32 | 2800 | 103 | 6.9 | 40 |
| WSA012025_12H | B/S/F | 12 | 7.0~13.2 | 0.64 | 3100 | 114 | 8.5 | 43 |
| WSA012025_24H | B/S/F | 24 | 14.0~26.4 | 0.38 | 3100 | 114 | 8.5 | 43 |
| WSA012025_12U | B/S/F | 12 | 7.0~13.2 | 0.96 | 3400 | 125.1 | 10.2 | 45 |
| WSA012025_24U | B/S/F | 24 | 14.0~26.4 | 0.6 | 3400 | 125.1 | 10.2 | 45 |
