Lagertyp: Zwei Kugellager
Material: Impeller &Rahmen: Kunststoff (UL94V-0)
Bleidraht: UL1007 im Kombi,AWG26
nbsp; Red Wire Positiv (+)
nbsp; Negativ (Black Wire)一)
Gewicht: 421.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA012038_12L | B | 12 | 7.0~13.2 | 0.08 | 4400 | 114.7 | 10.4 | 41 |
| WSA012038_24L | B | 24 | 14.0~26.4 | 0.05 | 4400 | 114.7 | 10.4 | 41 |
| WSA012038_48L | B | 48 | 28.0~56.0 | 0.19 | 4400 | 114.7 | 10.4 | 41 |
| WSA012038_12M | B | 12 | 7.0~13.2 | 0.15 | 5500 | 123.2 | 11.3 | 44 |
| WSA012038_24M | B | 24 | 14.0~26.4 | 0.21 | 5500 | 123.2 | 11.3 | 44 |
| WSA012038_48M | B | 48 | 28.0~56.0 | 0.12 | 5500 | 123.2 | 11.3 | 44 |
| WSA012038_12H | B | 12 | 7.0~13.2 | 0.25 | 6500 | 135.9 | 13.8 | 48 |
| WSA012038_24H | B | 24 | 14.0~26.4 | 0.13 | 6500 | 135.9 | 13.8 | 48 |
| WSA012038_48H | B | 48 | 28.0~56.0 | 0.45 | 6500 | 135.9 | 13.8 | 48 |
| WSA012038_12U | B | 48 | 28.0~56.0 | 0.31 | 7500 | 178.4 | 23.8 | 54 |
