Lagertyp: Zwei Kugellager
Material: Impeller &Rahmen: Kunststoff (UL94V-0)
Bleidraht: UL1007 im Kombi,AWG26
nbsp; Red Wire Positiv (+)
nbsp; Negativ (Black Wire)一)
Gewicht: 14.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA07008_05L | B/S/F | 5 | 3.5~5.5 | 0.1 | 3000 | / | / | 25 |
| WSA07008_12L | B/S/F | 12 | 7.0~13.2 | 0.06 | 3000 | / | / | 25 |
| WSA07008_05M | B/S/F | 5 | 3.5~5.5 | 0.18 | 4000 | / | / | 27 |
| WSA07008_12M | B/S/F | 12 | 7.0~13.2 | 0.1 | 4000 | / | / | 27 |
| WSA07008_05H | B/S/F | 5 | 3.5~5.5 | 0.32 | 5000 | / | / | 30.5 |
| WSA07008_12H | B/S/F | 12 | 7.0~13.2 | 0.2 | 5000 | / | / | 30.5 |
| WSA07008_05U | B/S/F | 5 | 3.5~5.5 | 0.5 | 6000 | / | / | 34 |
