Lagertyp: Zwei Kugellager
Material: Impeller &Rahmen: Kunststoff (UL94V-0)
Bleidraht: UL1007 im Kombi,AWG26
nbsp; Red Wire Positiv (+)
nbsp; Negativ (Black Wire)一)
Gewicht: 42.0g
| MODEL | Bearing System | Rated Voltage | Input Current | Power Consum ptlon (watts) | Speed | Noise |
| PART NO | B/S/F | VDE | AMP | watts | RPM | Db-A |
| WSA09015_05L | B/S/F | 5 | 0.35 | 1.75 | 2000 | 32 |
| WSA09015_05M | B/S/F | 5 | 0.5 | 2.5 | 3000 | 36 |
| WSA09015_12L | B/S/F | 12 | 0.2 | 2.4 | 2500 | 32 |
| WSA09015_12M | B/S/F | 12 | 0.35 | 4.2 | 3000 | 36 |
| WSA09015_12H | B/S/F | 12 | 0.55 | 6.6 | 3500 | 39.5 |
| WSA09015_24L | B/S/F | 24 | 0.2 | 4.8 | 2500 | 32 |
| WSA09015_24M | B/S/F | 24 | 0.3 | 7.2 | 3000 | 36 |
| WSA09015_24H | B/S/F | 24 | 0.4 | 9.6 | 3500 | 39.5 |
