Lagertyp: Zwei Kugellager
Material: Impeller &Rahmen: Kunststoff (UL94V-0)
Bleidraht: UL1007 im Kombi,AWG26
nbsp; Red Wire Positiv (+)
nbsp; Negativ (Black Wire)一)
Gewicht: 26.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA06010_12L | B/S/F | 12 | 7.0~13.2 | 0.13 | 3500 | 17.4 | 0.08 | 28 |
| WSA06010_24L | B/S/F | 24 | 14.0~26.4 | 0.08 | 3500 | 17.4 | 0.08 | 28 |
| WSA06010_12M | B/S/F | 12 | 7.0~13.2 | 0.17 | 4200 | 20.8 | 0.12 | 33 |
| WSA06010_24M | B/S/F | 24 | 14.0~26.4 | 0.11 | 4200 | 20.8 | 0.12 | 33 |
| WSA06010_12H | B/S/F | 12 | 7.0~13.2 | 0.24 | 4900 | 24.3 | 0.16 | 37 |
| WSA06010_24H | B/S/F | 24 | 14.0~26.4 | 0.15 | 4900 | 24.3 | 0.16 | 37 |
