Lagertyp: Zwei Kugellager
Material: Impeller &Rahmen: Kunststoff (UL94V-0)
Bleidraht: UL1007 im Kombi,AWG26
nbsp; Red Wire Positiv (+)
nbsp; Negativ (Black Wire)一)
Gewicht: 210.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA09238_12J | B | 12 | 7.0~13.2 | 0.11 | 4300 | 97.12 | 17.83 | 30 |
| WSA09238_24J | B | 24 | 14.0~26.4 | 0.08 | 4300 | 97.12 | 17.83 | 30 |
| WSA09238_48L | B | 48 | 28.0~56.0 | 0.06 | 4300 | 97.12 | 17.83 | 30 |
| WSA09238_12L | B | 12 | 7.0~13.2 | 0.14 | 5000 | 109.23 | 21.57 | 34 |
| WSA09238_24L | B | 24 | 14.0~26.4 | 0.13 | 5000 | 109.23 | 21.57 | 34 |
| WSA09238_48L | B | 48 | 28.0~56.0 | 0.08 | 5000 | 109.23 | 21.57 | 34 |
| WSA09238_12M | B | 12 | 7.0~13.2 | 0.2 | 6000 | 123.43 | 28.53 | 38 |
| WSA09238_24M | B | 24 | 14.0~26.4 | 0.15 | 6000 | 123.43 | 28.53 | 38 |
| WSA09238_48M | B | 48 | 28.0~56.0 | 0.12 | 6000 | 123.43 | 28.53 | 38 |
| WSA09238_12H | B | 12 | 7.0~13.2 | 0.35 | 7000 | 145.75 | 37.06 | 45 |
| WSA09238_24H | B | 24 | 14.0~26.4 | 0.2 | 7000 | 145.75 | 37.06 | 45 |
| WSA09238_48H | B | 48 | 28.0~56.0 | 0.41 | 7000 | 145.75 | 37.06 | 45 |
| WSA09238_12U | B | 12 | 7.0~13.2 | 0.3 | 8000 | 166.39 | 48.4 | 52.3 |
| WSA09238_24U | B | 24 | 14.0~26.4 | 0.2 | 8000 | 166.39 | 48.4 | 52.3 |
| WSA09238_48U | B | 48 | 28.0~56.0 | 0.41 | 8000 | 166.39 | 48.4 | 52.3 |
