Lagertyp: Zwei Kugellager
Material: Impeller &Rahmen: Kunststoff (UL94V-0)
Bleidraht: UL1007 im Kombi,AWG26
nbsp; Red Wire Positiv (+)
nbsp; Negativ (Black Wire)一)
Gewicht: 46.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA06025_05L | B/S/F | 5 | 3.5~5.5 | 0.2 | 2500 | 4.6 | 7.3 | 24.2 |
| WSA06025_12L | B/S/F | 12 | 7.0~13.2 | 0.1 | 2500 | 4.6 | 7.3 | 28 |
| WSA06025_05M | B/S/F | 5 | 3.5~5.5 | 0.3 | 3500 | 6.5 | 10.2 | 27 |
| WSA06025_12M, | B/S/F | 12 | 7.0~13.2 | 0.15 | 3500 | 6.5 | 10.2 | 32 |
| WSA06025_05H | B/S/F | 5 | 3.5~5.5 | 0.45 | 4000 | 7.4 | 11.7 | 32 |
| WSA06025_12H | B/S/F | 12 | 7.0~13.2 | 0.3 | 4000 | 7.4 | 11.7 | 38 |
| WSA06025_12U | B/S/F | 12 | 7.0~13.2 | 0.45 | 4500 | 8.3 | 13.2 | 42.5 |
